Bluetti EP760 Inverter

The Bluetti EP760 is a single-phase hybrid inverter for domestic energy storage systems. The model is compatible with Bluetti B500 battery modules and enables the creation of an emergency power supply system, a solar power storage system, as well as partial or fully autonomous operation of the home.

The EP760 is designed for a single-phase connection at 230 V and a frequency of 50 Hz. This makes it suitable for private homes, flats, small offices, technical rooms and premises where a reliable emergency power system is required without a three-phase configuration.

The inverter’s rated output power is 7.6 kW. This capacity is sufficient for most essential household appliances: lighting, fridges, routers, computer equipment, CCTV systems, pumps, boilers, kitchen appliances and other devices within the permissible load limits.

The system has a modular design and supports B500 battery packs. The system’s capacity can be adjusted from 9.92 kWh (2 × B500) to 19.84 kWh (4 × B500). This range allows the configuration to be adapted to various requirements: from a short-term backup for critical appliances to prolonged autonomous operation of key household appliances.

One of the advantages of the EP760 is that it supports both AC and DC coupling. This simplifies integration into new or existing solar installations. The inverter can be used as part of a new energy system or as a solution for modernising an existing system that already generates solar power.

The maximum power of the PV input is 9 kW. The MPPT range is 150–500 V, the nominal value is 360 V and the maximum current per MPPT input is 12.5 A. There are 3 independent MPPT inputs, which allow for more flexible connection of solar modules and more efficient operation with different orientations or groups of modules.

The system supports switchover to emergency power supply in less than 10 ms. This is important for equipment that must not be switched off abruptly in the event of a power cut. The EP760 can maintain the operation of network devices, computers, security systems, lighting and other critical equipment.

The inverter has an IP65 protection rating and is therefore better protected against dust and moisture. The operating temperature range is between –20 °C and +50 °C, with a noise level of up to 50 dB. This means the unit can be installed in plant rooms or sheltered outdoor areas.

Wi-Fi and Bluetooth are provided for communication and control. The monitoring system allows you to track the inverter’s operation, the state of charge of the batteries, solar power generation and current consumption. This is useful for the day-to-day monitoring of the energy system and for optimising the use of stored energy.

The inverter measures 532 × 325 × 370 mm and weighs 46 kg. These are stationary units that require professional installation, the selection of B500 batteries, protective devices and solar panels, and connection to the mains supply in accordance with the requirements of the property.

The Bluetti EP760 is a practical solution for single-phase energy storage systems in private households. It combines an output power of 7.6 kW, support for B500 batteries with up to 19.84 kWh, a PV input of up to 9 kW, 3 MPPT inputs, support for AC and DC coupling, a switchover time of less than 10 ms, IP65 protection, Wi-Fi, Bluetooth and a 10-year warranty.
