Pramac TG 72/15 400V AVR tractor generator

ThePramac TG72/15 IP44 is a powerful tractor PTO-driven generator designed for agricultural, municipal and backup applications where an autonomous power source without a separate engine is required. The model connects to the tractor’s PTO and provides a reliable 3-phase and 1-phase power supply for various equipment.

The generator operates at 400/230 V and delivers 51.8 kW of 3-phase power and 20.4 kW of 1-phase power. This makes the model a practical solution for powering both 3-phase loads and individual single-phase appliances, tools and equipment.

The Pramac TG72/15 IP44 does not have its own engine, fuel tank or starting system, as it is driven by the tractor’s power take-off (PTO). The model requires a tractor with a power output of at least 118 kW / 160 hp, and the recommended PTO speed is 395 rpm.

The model is equipped with electronic AVR voltage regulation, which helps maintain a very accurate and stable output voltage under load. The technical data sheet for the generator specifies a voltage accuracy of 0.5%, and it is fitted with a voltmeter, a frequency meter and a minimum and maximum voltage controller.

For connecting loads, the generator has 1 SCHUKO 230 V 16 A IP54 socket, 1 3P+N+T CEE 400 V 63 A socket and 1 CEE 400 V 125 A socket. This provides flexibility in connecting equipment for domestic, field and emergency tasks.

The model has IP44 electrical protection, whilst the panel has IP54 protection, making it suitable for working conditions where reliability and durability are essential. The generator is also equipped with thermal-magnetic protection and residual current protection.

With dimensions of 1110×720×1322 mm and a weight of 470 kg, the Pramac TG72/15 IP44 is a reliable solution for farms, utility services and users who require a powerful PTO generator for a mobile power source driven by a tractor.
