    Pramac S 6000 400V diesel generator
    Pramac S 6000 400V diesel generator
    Is this product right for me? Ask an expert

    We use your details solely to process your enquiry and to contact you. More information in our Privacy Policy.



    Pramac S 6000 400V diesel generator

    €4,875.00
    VAT included
    14-day right of withdrawal

    Estimated dispatch: 24–26 November (3–5 working days after payment)

    In stock
    • Rated power, kW: 4.5
    • Maximum power, kW: 5.5
    • Voltage, V: 230/400
    • Number of phases: 3
    • Start type: Manual-electric-automatic
    MPN:
    PD572TY4002
    101418-53

    4.5 kW rated power.

    Maximum power 5.5 kW.

    Three-phase 400/230 V generator.

    Yanmar L100N Electric diesel engine.

    Electric start.

    Enlarged 24-litre fuel tank.

    Up to 16.44 hours of continuous operation.

    Quantity :
    • Expert adviceExpert advice
    • On-time deliveryOn-time delivery
    • Technical SupportTechnical Support
    • Secure paymentSecure payment

    The Pramac S6000 400V (24L) diesel generator — a professional solution for three-phase equipment

    The Pramac S6000 (24L) 400V 50Hz is a powerful three-phase diesel generator from the S series, providing a stable power supply for construction, manufacturing and backup use. Thanks to its large fuel tank and electric start, this model is ideal for long periods of autonomous operation.

    Three-phase power

    The generator delivers 4.5 kW of rated power and up to 5.5 kW in peak mode, enabling it to power three-phase equipment.

    Electric start

    The electric start significantly simplifies starting the generator and enhances user comfort.

    Long-lasting autonomous operation

    The 24-litre fuel tank provides up to 16.44 hours of operation at 75% load.

    Reliable diesel engine

    The Yanmar L100N Electric engine ensures stable operation, fuel efficiency and durability.

    Professional control panel

    Equipped with a CONN DPP panel featuring differential protection, an automatic circuit breaker and the option to connect an automatic start-up system (AMF).

    Pramac
    101418-53
    99 Items

    Data sheet

    Voltage, V
    230/400
    Maximum power, kW
    5.5
    Rated power, kW
    4.5
    Frequency, Hz
    50
    Sockets
    1x Schuko 230V 16A + 2x CEE 230V 16A + 1x CEE 400V 16A
    Fuel tank capacity, litres
    24
    Runtime at 100% load, h
    12.37
    Sound level Lpa (7 m)/Lwa, dB
    72/97
    Engine model
    Yanmar L100N Electric
    Type of engine
    Single-cylinder, 4-stroke, air-cooled diesel engine
    Fuel type
    Diesel
    Engine oil capacity, litres
    1.6
    Engine capacity, cm³
    435
    Voltage regulator
    Конденсаторний
    Start type
    Manual-electric-automatic
    Protection class
    IP23
    Net dimensions (LxWxH), mm
    840×641×696
    Net weight, kg
    124
    Power range, kW
    5 - 10
    Number of phases
    3
    Fuel consumption, litres per hour
    1.94
    Automatic transfer switch (ATS)
    Made to order
    Cooling system
    Air
    Warranty, months
    12

    Specific References

    MPN
    PD572TY4002
