• New
    400V diesel generator
    400V diesel generator

    400V diesel generator

    €4,875.00
    VAT included
    In stock
    • Voltage, V: 230/400
    • Maximum power, kW: 5.5
    • Rated power, kW: 4.5
    • Start type: Manual-electric-automatic
    • Runtime at 100% load, h: 12.37
    PD572TY4002
    99Items

    4.5 kW rated power.

    Maximum power 5.5 kW.

    Three-phase 400/230 V generator.

    Yanmar L100N Electric diesel engine.

    Electric start.

    Enlarged 24-litre fuel tank.

    Up to 16.44 hours of continuous operation.

    Quantity :

    The Pramac S6000 400V (24L) diesel generator — a professional solution for three-phase equipment

    The Pramac S6000 (24L) 400V 50Hz is a powerful three-phase diesel generator from the S series, providing a stable power supply for construction, manufacturing and backup use. Thanks to its large fuel tank and electric start, this model is ideal for long periods of autonomous operation.

    Three-phase power

    The generator delivers 4.5 kW of rated power and up to 5.5 kW in peak mode, enabling it to power three-phase equipment.

    Electric start

    The electric start significantly simplifies starting the generator and enhances user comfort.

    Long-lasting autonomous operation

    The 24-litre fuel tank provides up to 16.44 hours of operation at 75% load.

    Reliable diesel engine

    The Yanmar L100N Electric engine ensures stable operation, fuel efficiency and durability.

    Professional control panel

    Equipped with a CONN DPP panel featuring differential protection, an automatic circuit breaker and the option to connect an automatic start-up system (AMF).

    Pramac
    101418-53
    99 Items

    Data sheet

    Voltage, V
    230/400
    Maximum power, kW
    5.5
    Rated power, kW
    4.5
    Frequency, Hz
    50
    Sockets
    1x Schuko 230V 16A IP54 + 2x CEE 230V 16A IP44 + 1x CEE 400V 16A IP44
    Fuel tank capacity, litres
    24
    Runtime at 100% load, h
    12.37
    Sound level Lpa (7 m)/Lwa, dB
    72/97
    Engine model
    Yanmar L100N Electric
    Type of engine
    1-cylinder, 4-stroke, air-cooled diesel engine
    Fuel type
    Diesel
    Engine oil capacity, litres
    1.6
    Engine capacity, cm³
    435
    Voltage regulator
    Конденсаторний
    Start type
    Manual-electric-automatic
    Protection class
    IP23
    Net dimensions (LxWxH), mm
    840×641×696
    Net weight, kg
    124
    Power range, kW
    5 - 10
    Number of phases
    3
    Fuel consumption, litres per hour
    1.94
    Automatic transfer switch (ATS)
    Made to order
    Cooling system
    Air
    Warranty, months
    12

    Specific References

    MPN
    PD572TY4002
