    Pramac P 18000 400V AVR diesel generator
    Pramac P 18000 400V AVR diesel generator

    Pramac P 18000 400V AVR diesel generator

    €14,875.00
    VAT included
    In stock
    • Voltage, V: 230/400
    • Maximum power, kW: 14.79
    • Rated power, kW: 12.95
    • Start type: Electricity
    • Runtime at 100% load, h: 8.51
    PF183TY4007
    99Items

    Rated power: 12.95 kW.

    Maximum power 14.79 kW.

    Three-phase generator 400/230 V.

    Yanmar 3TNV80-FPGE engine.

    Electric start.

    AVR system.

    Up to 8.51 hours of operation.

    Quantity :

    Pramac P18000 400V AVR diesel generator

    The Pramac P18000 is a powerful three-phase diesel generator in a soundproof enclosure, designed for industrial use, construction and backup power supply for large facilities.

    Industrial power

    The generator delivers 12.95 kW of rated power and up to 14.79 kW of maximum power, enabling it to operate three-phase equipment.

    Reliable Yanmar engine

    Equipped with a Yanmar 3TNV80-FPGE liquid-cooled diesel engine, which guarantees stable operation even under prolonged loads.

    AVR stabilisation

    The AVR automatic voltage regulation system ensures precise voltage (±1.5%) to protect equipment.

    Industrial enclosure

    The galvanised soundproof enclosure ensures low noise levels and protection from the elements.

    Pramac
    101418-67
    99 Items

    Data sheet

    Voltage, V
    230/400
    Maximum power, kW
    14.79
    Rated power, kW
    12.95
    Frequency, Hz
    50
    Sockets
    2x Schuko 230V 16A + 1x CEE 400V 16A + 1x CEE 400V 32A
    Fuel tank capacity, litres
    51
    Runtime at 100% load, h
    8.51
    Sound level Lpa (7 m)/Lwa, dB
    67/96
    Engine model
    Yanmar 3TNV80-FPGE
    Type of engine
    Дизельний 3-циліндровий, 4-тактний з рідинним охолодженням
    Fuel type
    Diesel
    Engine oil capacity, litres
    4.4
    Engine capacity, cm³
    1267
    Voltage regulator
    Intelligent AVR system
    Start type
    Electricity
    Protection class
    IP23
    Net dimensions (LxWxH), mm
    1500×754×1032
    Net weight, kg
    475
    Power range, kW
    10 - 20
    Number of phases
    3
    Fuel consumption, litres per hour
    5.99
    Automatic transfer switch (ATS)
    No
    Cooling system
    Air
    Warranty, months
    12

    Specific References

    MPN
    PF183TY4007
